Titanium rod bar-ASTM B348-F67-F136-ISO-5832-ASEM SB438-AMS 4928

We have titanium and titanium alloys round bar 100 Tons in stock with complete specifications.
We work with you to ensure efficient stock planning, which ensures that a wide range of stock is available. You will be surprised to know how many popular items are available from our warehouse with send available within 24 hours.
  • Gr.1/ Gr.2/ Gr.3/ Gr.4/ Gr.5/ Gr.7/ Gr.9/ Gr.11/ Gr.12
  • Dia:2mm to 300mm
  • Ti-Bar-06


Specification

ASTM B348/ ASME SB348 /ASTM F136/ ASTM F67/ AMS4928/DIN17862 /ISO5832/ MIL-T-9047/JIS/OCT

Grade

Gr.1/ Gr.2/ Gr.3/ Gr.4/ Gr.5/ Gr.7/ Gr.9/ Gr.11/ Gr.12 etc..


titanium bar.jpg




Chemical requirements

Grade N C H Fe O Al V Pa Mo Ni Ti
Gr 1 0.03 0.08 0.015 0.2 0.18 / / / / / bal
Gr 2 0.03 0.08 0.015 0.3 0.25 / / / / / bal
Gr 3 0.05 0.08 0.015 0.3 0.35 / / / / / bal
Gr 4 0.05 0.08 0.015 0.5 0.4 / / / / /
Gr 5 0.05 0.08 0.015 0.4 0.2 5.5~6.75 3.5~4.5 / / / bal
Gr 7 0.03 0.08 0.015 0.3 0.25 / / 0.12~0.25 / / bal
Gr 9 0.03 0.08 0.015 0.25 0.15 2.5~3.5 2.0~3.0 / / / bal
Gr12 0.03 0.08 0.015 0.3 0.25 / / / 0.2~0.4 0.6~0.9 bal



Tensile requirements


Grade Tensil strength(min) Yeild strength(min) Elongation(%)
ksi MPa ksi MPa
1 35 240 20 138 24
2 50 345 40 275 20
3 65 450 55 380 18
4 80 550 70 483 15
5 130 895 120 828 10
7 50 345 40 275 20
9 90 620 70 438 15
12 70 438 50 345 18
